Product Features OSFP MSA compliant 4 CWDM lanes MUX/DEMUX design 100G Lambda MSA 400G-FR4 Specification compliant Up to 2km transmission on single mode fiber (SMF) with FEC Operating case temperature: 0 to 70oC 8x53.125Gb/s electrical interface (400GAUI-8) Data Rate 106.25Gbps (PAM4) per channel. Maximum power consumption 12W Duplex LC connector RoHS compliant
The QSFP112 400GBASE LR4 transceiver module is designed for 400G Ethernet links over 10km of single-mode fiber. The module contains 4 parallel channels at a center wavelength of CWDM, each operating at 106.25G. On the receiver path, 4 photodiodes and a 4-channel TIA array are used, along with PAM4 re-timers.
