12G Video SFP+ Optical Transceiver support 4K 60HZ Video

The FiberWDM RQD-200G10-PSM8 is a Eight-Channel, Pluggable, Parallel, Fiber-Optic QSFP DD PSM8 for 2×100 Gigabit Ethernet , Infiniband DDR/EDR Applications. This transceiver is a high performance module for data communication and interconnect applications. It integrates eight data lanes in each direction with 208 Gbps bandwidth. Each lane can operate at 26Gbps up to 10km over G.652 SMF. These modules are designed to operate over singlemode fiber systems using a nominal wavelength of 1310nm. The electrical interface uses a 76 contact edge type connector. The optical interface uses an 24 fiber MTP (MPO) connector. This module incorporates FiberWDM proven circuit and Optical technology to provide reliable long life, high performance, and consistent service.

With the rapid development of 5G, IoT and other emerging technologies, bandwidth demand is growing. To meet this demand, Passive Optical Network (PON) technologies are evolving accordingly. The current mainstream PON technologies, GPON and XGS-PON, coexist on the same fiber via Wavelength Division Multiplexing (WDM), thus boosting network bandwidth and flexibility.

Single-fiber bidirectional transmission：Supports 2-channel Drop/Add services over a single fiber, optimizing scarce fiber resources. Low insertion loss：≤1.5dB for wave-to-line, ≤2.4dB for west-east/east-west transmission, ensuring efficient signal propagation. High isolation：≥30dB adjacent channel isolation and ≥45dB non-adjacent isolation, minimizing crosstalk. Wide temperature tolerance：Operates/stores between -40°C to 85°C, suitable for extreme environmental conditions. Modular deployment：FMU plug-in module compatible with 2-slot 1U rack or LGX BOX for flexible installation.

RO-1T6-2xFR4 is designed to transmit and receive serial optical data links up to 212.5 Gb/s data rate (per channel) by PAM4 modulation format over single-mode fiber. It is a small-form- factor hot pluggable transceiver module integrated with high performance EML laser. It is compliant with 1600G Ethernet specs and OSFP-XD MSA.

IL<6.0dB , 100GHZ DWDM AAWG Technology Fully Compatible with All ITU-T 1G/10G/25G/40G/100G DWDM Optics Passive devices, No Power No Cooling Required Support Metro, Regional and Long Haul DWDM Networks

Three-port optical passive device Meets Telcordia GR-1221-CORE requirements High stability and reliability

The RQ-100GDO25-XXXX series single mode transceiver module is designed for multiple channel 100GbE transmissions for up to 25km distance over standard G.652 single mode optical fiber (SMF) . The transceiver operates at a data rate of 100Gbps at the nominal DWDM wavelength from 1295.56nm to 1312.58nm as specified by the CW-WDM MSA. This module can convert 4 channels of 25Gbps (NRZ) electrical input data to 1 channel of 100Gbps (PAM4) optical signal, and also can convert 1 channel of 100Gbps (PAM4) optical signal to 4 channels of 25Gbps (NRZ) electrical output data. The electrical interface of the module is compliant with the OIF CEI-28G-VSR and QSFP28 MSA. It is designed to deploy in the RQ-100GDO25-XXXX SeriesQSFP28 100G O-Band DWDM 25KM SM LC Transceiver DWDM networking equipment in metropolitan access and core networks

1310nm port can support 1G LX/SX, 10G LR, 40G ER4/LR4, 100G LR/ER4/LR4/ZR4; it for Existing Legacy Traffic. Mon port is for network link monitoring or power monitoring, easy troubleshooting without affecting traffic.
