EDFA Optical Amplifier
EDFA Optical Amplifier EDFA Optical Amplifier EDFA Optical Amplifier

EDFA Optical Amplifier Module


  • High output power up to23dBm
  • Flexible control mode
  • High stability and reliability
  • Operating temp. -20~60°C
  • Customizable output power and configuration


Inquire now
  • Product Detail

EDFA Optical Amplifier Module


FIBERWDM's Low noise figure EDFA module is widely used in optical fiber sensing and communications. It consists of a 980 nm or 1480 nm pump laser to provide energy and operates in AGC, ACC or APC mode.


Based on fine temperature control technology inside, it provides excellent temperature characteristics even under harsh working environment at the temperature of -20~60°C.


It features high output power, a large gain, and a variable gain range >20dB. It can work across C-band and L-band meeting customers’diverse needs.


It uses DC+5V/GND or DC+3.3V/GND as power supply, user-friendly RS232 serial port as communications interface for easy internal configuration, enabling real-time parameter monitoring, and remote management and control of the line.



Features

  • High output power up to  23dBm
  • Flexible control mode
  • High stability and reliability
  • Operating temp. -20~60°C
  • Customizable output power and configuration

Applications


  • Long Haul optical fiber communication
  • Dense Wavelength Division Multiplexing
  • National defense and military
  • Optical fiber sensing
  • Oil and gas field monitoring


Optical Specifications


Parameter

Unit

Minimum

Typical Value

Maximum

Operating Wavelength Range

nm

1528

1550

1563

Total Input Power

dBm

-

0

-

Saturation Output Power

@Pin=0 dBm

dBm

-

-

23

Noise Figure @Pin=0 dBm

dB

-

5.5

-

PDG

dB

-

-

0.5

PMD

PS

-

-

0.5

Input/ Output Isolation

dB

40

-

-

Output Power Adjustability

Yes

Fiber Type (Single Mode)

SMF 9/125um NA=0.13

Fiber Length

Customizable

Connectors

FC/APC, other types are optional

Operating Temperature Range

℃

-20

-

+60

Storage Temperature Range

℃

-40

-

+85

Humidity

%

5

-

90

(1) Testresult at single temperature.

(2) No condensation.



Mechanical Structure


Structure Type

Parameter

Specification

Unit

Remarks



Module

Dimension

90x70x15/90x70x12

mm



Power Interface

DC+5V/GND or DC+3.3V/GND



Typical

Output Pigtail

SM





Communication Interface

RS-232



Optional


Connector Type


Connector:20-pin 2.0mm connector LVTTL


Pin

Name

P

Level

1

+5V

P


2

+5V

P


3

GND

P


4

GND

P


5

Serial port input

I

LVTTL

6

 Serial port output

O

LVTTL

7

GND

P


8

GND

P


9

Hardware shutoff pump, high level efficient

I

LVTTL

10

Reset, low level efficient

I

LVTTL

11

 Module Temperature Alarm (High Level Effective)

O

LVTTL

12

Eye protection mode (high level effective)

I

LVTTL

13

Pump temperature alarm (high level effective)

O

LVTTL

14

Pump current alarm (high level effective)

O

LVTTL

15

 Input Alarm (High Level Effective)

O

LVTTL

16

Output alarm (high level valid)

O

LVTTL

17

GND

P


18

GND

P


19

+5V

P


20

+5V

P


Note1:

P：Power；I：Input；O：Output；F：N。

Note3:

External reset input is low level valid.
