Features:                                               Up to 1.25Gb/s Data Links Hot-Pluggable Single LC connector Up to 180km on 9/125μm SMF 1550nm DFB laser transmitter APD Receiver Single +3.3V Power Supply Monitoring Interface Compliant with SFF-8472 Power dissipation<1.5W operating temperature range: 0°C to 70°C  RoHS compliant and Lead Free Applications: 1000Base-ZX Ethernet Metro/Access Networks 1×Fibre Channel Other Optical Links

Features: Up to 2.67Gb/s Data Links Hot-Pluggable Duplex LC connector Up to 80km on 9/125μm SMF CWDM DFB laser transmitter APD receiver Single +3.3V Power Supply Monitoring Interface Compliant with SFF-8472 Maximum Power <1W Industrial /Extended/ Commercial operating temperature range: -40°C to 85°C/-5°C to 85°C/-0°C to 70°C Version available RoHS compliant and Lead Free Applications: Gigabit Ethernet Fiber Channel Switch Infrastructure Router/Server interface Other optical transmission systems

Features: 4 lanes MUX/DEMUX design 100GHz ITU Grid, C Band DWDM EML transmitter, APD photo-detector Up to 11.2Gbps per channel bandwidth Aggregate bandwidth of > 40Gbps Duplex LC connector Compliant with 40G Ethernet IEEE802.3ba and 40GBASE-EZR4 QSFP MSA compliant Up to 100 km transmission Compliant with QDR/DDR Infiniband data rates Single +3.3V power supply operating Built-in digital diagnostic functions Temperature range 0°C to 70°C RoHS Compliant Part Applications: Rack to rack Data centers Switches and Routers Metro networks Switches and Routers 40G BASE-EZR4

Features: Support multi protocol from 9.95Gb/s to 11.3Gb/s Hot pluggable 30 pin connector Compliant with XFP MSA Transmission distance of 80km over single mode fiber DWDM EML laser transmitter APD Receiver 100GHz ITU Grid, C Band Duplex LC connector 2-wire interface for management and diagnostic monitor XFI electrical interface with AC coupling Power supply voltages: +3.3V, +5V Temperature range 0°C to 70°C Power dissipation: <3.5W RoHS Compliant Part Applications: 10GBASE-ER/EW Ethernet SONET OC-192 /SDH 80km 10G FC DWDM Networks Transceiver Types:

Features: Support multi protocol from 9.95Gb/s to 11.3Gb/s Hot pluggable 30 pin connector Compliant with XFP MSA Transmission distance of 40km over single mode fiber DWDM EML laser transmitter 100GHz ITU Grid, C Band Duplex LC connector 2-wire interface for management and diagnostic monitor XFI electrical interface with AC coupling Power supply voltages: +3.3V, +5V Temperature range 0°C to 70°C Power dissipation: <3.5W RoHS Compliant Part Applications: 10GBASE-ER/EW Ethernet SONET OC-192 /SDH 40km 10G FC DWDM Networks Transceiver Types:

Features: Support multi protocol from 9.95Gb/s to 11.3Gb/s Hot pluggable 30 pin connector Compliant with XFP MSA Transmission distance of 80km over single mode fiber Cooled EML laser transmitter. APD Receiver Duplex LC connector 2-wire interface for management and diagnostic monitor XFI electrical interface with AC coupling Power supply voltages: +3.3V, +5V Temperature range 0°C to 70°C Power dissipation: <3.5W RoHS Compliant Part Applications: 10GBASE-ZR/ZW Ethernet SONET OC-192 / SDH STM-64 ITU-T G.959.1 P1L1-2D2 80km 10G FC Other optical links Transceiver Types:

Features: Support multi protocol from 9.95Gb/s to 11.3Gb/s Hot pluggable 30 pin connector Compliant with XFP MSA Transmission distance of 40km over single mode fiber Cooled EML laser transmitter. Duplex LC connector 2-wire interface for management and diagnostic monitor XFI electrical interface with AC coupling Power supply voltages: +3.3V, +5V Temperature range 0°C to 70°C Power dissipation: <3W RoHS Compliant Part Applications: 10GBASE-ER/EW Ethernet SONET OC-192 IR-2/SONET OC-192 IR-3/SDH STM S-64.2b/SDH STM S-64.3b 40km 10G FC Other optical links Transceiver Types:

Features: Support multi protocol from 9.95Gb/s to 11.3Gb/s Hot pluggable 30 pin connector Compliant with XFP MSA Transmission distance of 10km over Single mode fiber 1310nm DFB laser transmitter. Duplex LC connector 2-wire interface for management and diagnostic monitor XFI electrical interface with AC coupling Single power supply voltages: +3.3V Temperature range 0°C to 70°C Power dissipation: <1.5W RoHS Compliant Part Applications: 10GBASE-LR/LW Ethernet SONET OC-192 /SDH 1200-SM-LL-L 10G Fiber Channel Other optical links Transceiver Types:
