25G SFP28 CWDM Optical Transceiver

25G SFP28 MWDM optical transceiver module, support 25Gb/s and up to 10 km transmission, it works in high-speed IDC connection solutions, 5G network front-haul solution, and so on.

25G SFP28 LWDM optical transceiver module, support 25Gb/s and up to 10 km transmission, it works in high-speed IDC connection solutions, 5G network front-haul solution, and so on.

25G SFP28 DWDM optical transceiver module, support 25Gb/s and up to 10 km transmission, it works in high-speed IDC connection solutions, 5G network front-haul solution, and so on.

25G SFP28 Bi-direcation optical transceiver module, support 25Gb/s and up to 10 km transmission, it works in high-speed IDC connection solutions, 5G network front-haul solution, and so on.

25G SFP28 optical transceiver module, support 25Gb/s and SR up to 100 m transmission, LR 25G SFP28 up to 10 km transmission, and ER 25G SFP28 up to 40 km transmission, it works in high-speed IDC connection solutions, and so on.

Product Features   Supports up to 25.78Gbps bit rates Hot-pluggable SFP+ footprint Up to 40km for SMF transmission Compliant with SFP+ MSA and SFF-8472 with duplex LC receptacle Compatible with RoHS Single +3.3V power supply2 Real Time Digital Diagnostic Monitoring Operating case temperature: Standard:  0 to +70°C

2-16ch DWDM mux, Low Insertion Loss, High Isolation, Low PDL Wide Operating Wavelength: C-Band ITU ( C17~ C61) Wide Operating Temperature: -20 to 70°C

The 100G FR1 SFP56-DD optical transceiver, 100G SFP56-DD FR1 is designed for using in 100-Gigabit Ethernet links up to 2km over Single-Mode Fiber (SMF). It is compliant with the SFP56-DD MSA,IEEE802.3CU,100G Lambda 100G FR1 and 100GAUI-2(no FEC)1. Digital diagnostics functions are available via the I2C interface, as specified by the SFP56-DD MSA. The module incorporates 1 channel optical signal, on 1311nm center wavelength, operating at 100Gbps data rate. This module can convert 2 channels of 53Gbps (PAM4) electrical input data to 1 channel of 106Gbps (PAM4) optical signal, and also can convert 1 channel of 106Gbps (PAM4) optical signal to 2 channels of 53Gbps (PAM) electrical output data. The optical interface uses a Duplex LC connector. The high performance cooled EML transmitter and high sensitivity PIN receiver provide superior performance for 100Gigabit Ethernet applications up to 2km links.
